Android 11
5G Mobile Hight Speed WI-FI
KT-M2H
Putting high-speed internet in your pocket.
What makes Kingtop MIFI Different?
5G MediaTek
Dimensity 900
Support CA/ENDC
Professional management platform
Modem compatible
12 hours of typical
usage
Up to 1201Mbps(802.11ax)
MediaTek chipset, smoother internet browsing
Mature manufacturing processes and global network compatibility testing. Equipped with MTK chip and eight core CPU architecture chip, the theoretical peak can be increased to 3.5Gbps;
Rocket Speed
3.5 Gbps theoretical download rate
NSA/SA
5G dual-mode network, 4G compatible
Sub-6G
Supports mainstream operator bands
ISP
Supports mainstream operator certification
Global mainstream frequency bands CA/ENDC
Advanced carrier aggregation technology brings higher user data rates.
Lower latency, higher capacity, more reliable network services, and better performance.
User-friendly management interface
*Easy to manage: Friendly operation interface, support WEB terminal, mobile phone terminal.
*Easy maintenance: support FOTA/TR069 remote upgrade and management.
PC/Mobile end adaptive
TR069/FOTA remote management
Device directly connected to modem
Stable high-speed connection, maximising the use of cellular capacity and USB3.0 data transfer capability.
Lower power consumption, longer battery life
4400 mAh large battery, support more than 12 hours of life in general use scenarios.
4400 mAh
High capacity battery
12 hours
Working time
478 hours
Standby time
Rich scenarios to enjoy network
Product Technical Specifications
Operating System
Platform
Chipset : MTK900，6nm 2*A78（2.4GHz）+6*A55（2.0GHz），GPU：Mali OTR MC4
Memory: LPDDR4X 2GB RAM+EMMC 8GB ROM
WIFI : MT6635
BT : Bluetooth 5.1, optional
Memory: LPDDR4X 2GB RAM+EMMC 8GB ROM
WIFI : MT6635
BT : Bluetooth 5.1, optional
LCM
LCD: 2.4''TFT MIPI（LCD or LED）
TP : Support
TP : Support
LED
Red, Green, Blue
WIFI
Bands : 2.4G, 5.8G
Protocal : 802.11 a/b/g/n/ac/ax
Throughput:
802.11a : Up to 54Mbps
802.11b : Up to 11Mbps
802.11g : Up to 54Mbps
802.11n : Up to 300Mbps
802.11ac : Up to 866Mbps
802.11ax : Up to 1201Mbps
Protocal : 802.11 a/b/g/n/ac/ax
Throughput:
802.11a : Up to 54Mbps
802.11b : Up to 11Mbps
802.11g : Up to 54Mbps
802.11n : Up to 300Mbps
802.11ac : Up to 866Mbps
802.11ax : Up to 1201Mbps
Interface
SIM card : NANO SIM card, eSIM optional
USB : TYPE-C, 5V/2A，5V/3A，9V/2A
Charge : TYPE-C, 5V/3A
USB : TYPE-C, 5V/2A，5V/3A，9V/2A
Charge : TYPE-C, 5V/3A
Polymer Battery
4400 mAh， could be customized
Size
125*70*17mm (could be customized.)
Scan QR code to log in the setting Web page
Scan QR code to log in the setting Web page, get connected, and customize your wifi hotspot’s settings in a snap.
And, the intuitive screen on the device itself is clear and easy to navigate so that you can quickly monitor your
Wi-Fi connections, identify your WiFi name/password, and more.
